Bauder low-temperature and high-temperature resistant solenoid valves – 200-180burkert 6026 Technical Data: Dimensions
For detailed information on dimensions see chapter “3. Dimensions” on page 4.
Material
Seals PTFE
Brass body with stainless steel seat 1.4581
Stainless steel with stainless steel seats 1.4581
Metal bellows Stainless steel 1.4541
Weight 1.1 kg
See “2. Circuit Functions” on page 3 for more information.
Performance Data
Duty cycle Continuous operation 100 % ED
Intermittent operation 50 % ED max. 6 times/min2)
Electrical data
Operating voltage 24 UC1…)
110…. …120 V/50… .60 Hz
230…. .240 V/50… .60 Hz 230… .240 V/50… .60 Hz .60 Hz
Voltage Tolerance Maximum ± 10
Power consumption 85/8 W
Media data
Media temperature – 200 °C… + 180 °C
Operating medium Neutral gases and fluids
Viscosity Ca.
Approvals and certificates
Protection class IP65 with cable plug
Process/port connections and communication
Electrical connections Labeling connectors according to DIN EN 175 301 – 803 A
(see “5.4. Accessory order form” on page 7)
Environment and mounting
Mounting position The actuator should preferably be mounted vertically, if required.
Ambient temperature (max.) + 55 °C Bauder low-temperature and high-temperature resistant solenoid valves – 200-180burkert
