Connection: Threaded connection Rp 1/4“-1/2” (brass) Threaded connection Rp 3/8“-Rp2” (ISO 7/1) Flanged connection DN40-DN150 (ISO 7005) Rated voltage: 230V AC 50/60Hz110V AC 50/60Hz24V AC/DC
12V AC/DC
Voltage Tolerance:-15%-+10
Power consumption: see table
Operating Temperature:-15℃℃-+60℃
Working pressure: Maximum 200/360 mbar(20Kpa/36kpa)
Flow coefficient: see table
Opening/closing time: <1 sec.
Filtration level: 600 μm. metal mesh (except brass) Protection level: standard IP54 (EN60529) (optional IP65) Cable wire: junction box type ISO 16 (EN50262)
Standard plug type PG 9
Coil insulation class: Class H (200°C) Coil heat resistance class: Class F (155°C) Seal material: NBR rubber (butyl rubber) Body material: Die-cast aluminum alloy
Pressure measurement orifice: Both sides G 1/4 (except brass series)
