1800CPB2 Series Regulator
The 1800CPB2 Series Regulator is a medium-sized spring-loaded regulator in the AMC0 series. Its body is pre-cast from cast iron, which prevents thread damage and allows easy conversion to a monitoring regulator. This series of regulators features a wide flow range, high precision, and high shut-off pressure. The flow orifice is compatible with two standard types and the 0PS0 type. The 0PS0 type provides ultra-high pressure shut-off, suitable for protecting public facilities such as schools and churches. It is also applicable to various industrial users. Applicable ambient temperature: -30℃ to +65℃.
Main Technical Parameters:
- Maximum Inlet Pressure: 8.79 kgf/cm
- Outlet Pressure: 6.90 kPa ～ 206.9 kPa
- Regulation Accuracy: +1% (absolute outlet pressure)
- Maximum Flow Rate: 289 Nm³/h
- Operating Temperature: -30℃ ～ 65℃
- Valve Body 180° Connections: 3/4″, 3/4″x1″, 1″, 1″x1-1/4″, 1-1/4″ NPT threads
- Valve Body 90° Connections (only for model 1803CPB2): 3/4″, 3/4″x1″, 1″ NPT threads
- Standard Configuration: 3/4″, 1″, 1-1/4″ NPT threads
Features: Pilot-operated regulator, capable of precisely controlling outlet pressure
Models & Additional Functions:
- 1803CPB2
- 1883CPB2
- Ultra-high pressure pilot valve
