1800(HC) series regulator
Main technical parameters:
Maximum inlet pressure: 8.79 kgf/cm²
Outlet pressure: 0.87 kPa~13.8 kPa
Maximum flow rate: 70.8 Nm³/h (1800C), 139 Nm³/h (1800C-HC)
Operating temperature: -30℃~65℃
Valve body connections: 3/4″, 3/4″x1″, 3/4″x1-1/4″, 1″, 1″x1-1/4″
NPT thread Offset valve body: 3/4″, 3/4″x1″, 1″ NPT thread
Standard configuration: 3/4″, 1″, 1-1/4″ NPT thread.
Model
Additional Features
Vent Hole
1813C
Full Internal Venting
3/4″ or 1″ NPT
1813C-HC
Full Internal Venting, Overpressure Shutdown
3/4″ or 1″ NPT
1843C
Full Internal Venting, Overpressure Shutdown, Low Pressure Shutdown
3/4″ or 1″ NPT
1843C-HC
Full Internal Venting, Overpressure Shutdown, Low Pressure Shutdown
3/4″ or 1″ NPT
1853C
Full Internal Venting
3/4″ or 1″ NPT
1853C W/USSA
Full Internal Venting with USSA
3/4″ or 1″ NPT
1853C-HC
Full Internal Venting, Overpressure Shutdown, Low Pressure Shutdown
3/4″ or 1″ NPT
1853C-HC w/USSA
Full Internal Venting, Overpressure Shutdown, Low Pressure Shutdown with USSA
3/4″ or 1″ NPT
