2000 Series Pressure Regulators
The 2000 series pressure regulators are medium-sized, spring-loaded regulators from AMCO, designed to complement the 1800 series regulators by offering higher outlet pressures. These regulators provide a wide range of flow rates, high accuracy, and tight shut-off pressure, making them suitable for various industrial users and applications, including industrial furnaces and kilns. They operate effectively within an ambient temperature range of -30℃ to +60℃.
Key Technical Parameters:
2000 Series Pressure Regulators
Maximum Inlet Pressure: 10.6 kgf/cm²
Outlet Pressure: 3.45 kPa to 103.4 Pa
Maximum Flow Rate: 566 Nm³/h
Operating Temperature: -30℃ to 65℃
Body Connections: 1-1/2”, 2” NPT Thread, 2” Flange
Standard Configuration: 1-1/2”, 2” NPT Thread
Model
Function
2003
None
2003M
Monitor Pressure Regulation
2023
Low Pressure Cutoff
2083
Overpressure Cutoff
2083M
Overpressure Cutoff, Monitor Pressure Reduction
2093
Overpressure Cutoff, Low Pressure Cutoff
