Itron B38 Series is a robust, spring-loaded gas pressure regulator designed for large-capacity commercial and industrial applications. It offers precise pressure control and rapid response, ideal for utility services, gas engines, burner trains, furnaces, and boilers.
Key Technical Specifications:
- Model Variants: B38R (with internal relief), B38N (non-relief), B38M (monitor)
- Connections: 1-1/2" NPT, 2" NPT, 2" Flanged, 3" Flanged
- Max Inlet Pressure: Up to 125 PSIG (8.6 bar)
- Outlet Pressure Range: 2.3" w.c. to 7.8 PSIG (0.57 mbar to 0.54 bar), spring-dependent
- Flow Capacity: Up to 20,000 SCFH (566 m³/h)
- Operating Temp: -20°F to 150°F (-29°C to 66°C)
- Orifice Sizes: 1/4" to 1-3/8" (field-interchangeable)
- Body Material: High-tensile cast iron (ASTM A-126, Class A)
