ITRON Commercial and Industrial Regulators RB4000 Series
Commercial and Industrial Regulators RB4000 Series
Model: RBE4011 Pressure Regulator/RBE 4012 Regulator RBE4021 Pressure Regulator/RBE 4022 Regulator RBE4031 Pressure Regulator/RBE4041 Regulators
The RBE4000 series of pressure regulators are suitable for the regional regulating stations, large-scale industrial users, etc., who need the regulators to make a quick response, and the built-in balancing compensation system ensures that the outlet pressure can be stabilized even if the inlet pressure varies greatly. RBE4000 series regulator can be equipped with SSV8600 shut-off valve, which is equipped with reset handle and can be installed with remote control system.
Spring-loaded quick-response regulator, balanced valve design eliminates inlet pressure effect, large flow rate, high precision, easy maintenance, damping device eliminates resonance and reduces surge, optional safety cut-off device Technical features: Inlet pressure: 19 bar Outlet pressure: 10 mbar – 2.0 bar Flow rate up to: 10,000Nm3/Hr Regulating accuracy Class: AC5 Closing pressure class: SG10 Operating temperature: -20 ℃ to +60 ℃ Connection caliber: DN 25, 40, 50, 50 x 80, 80 and 100
| RBE4731 | DN25/PN25 | 25bar | 0.5-2.5bar | 1.4-2.4bar |
| RBE4731 | DN25/PN25 | 1.5-5.5bar | 2.3-4.1bar | |
| RBE4731 | DN25/PN25 | 4-13bar | 7.5-10bar | |
| RBE4731 | DN50/PN25 | 1.5-5.5bar | 6.3-10.8bar | |
| RBE4731 | DN50/PN25 | 4-13bar | 10-15bar | |
| RBE4731 | DN80/PN25 | 1.5-5.5bar | 6.3-10.8bar | |
| RBE4731 | DN80/PN25 | 4-13bar | 10-15bar | |
| RBE4731 | DN100/PN25 | 1.5-5.5bar | 6.3-10.8bar | |
| RBE4731 | DN100/PN25 | 4-13bar | 10-15bar |
