Honeywell AMCO Sleeve 600 Axial Flow Valve Regulator - Precision Flow Control Solution
Honeywell AMCO Sleeve 600 regulator ensures precise flow control for axial flow valves in industrial applications.
Product Details
B7
V7
- 2″：73677P011
- 4″：73677P012
- 2″：73677P007
- 4″：73677P008
- 6″：73677P009
H7
- 2″：73677P001
- 4″：73677P003
- 6″：73677P004
Precision Flow Control The Sleeve 600 features advanced sleeve-type design technology that provides exceptional throttling accuracy and stable pressure control. Its innovative construction allows for smooth modulation across a wide range of flow rates, making it ideal for applications requiring precise gas delivery.
Robust Construction Built with high-quality materials, the AMCO Sleeve 600 is engineered to withstand harsh industrial environments. The regulator incorporates corrosion-resistant components and is designed for long service life even in challenging conditions.
Key Technical Features
- Wide operating pressure range for versatile applications
- High flow capacity with minimal pressure drop
- Accurate setpoint control with excellent repeatability
- Compact design for easy installation
Low maintenance requirements reducing operational costsHoneywell AMCO AFV-600 (Axial Flow Valve) is a pilot-operated regulator designed for pressure regulation, over-pressure relief, flow control, or on/off valve service in high-pressure gas systems. The flexible element sleeve design provides tight shutoff and precise modulating control over a wide range of flow conditions. The valve is composed of three main sections: valve body, control manifold, and actuator.
Pressure Ratings:
- Maximum Inlet Pressure: 1480 PSIG (102 bar)
- Outlet Pressure Range: 6" W.C. to 900 PSIG
- Maximum Differential Pressure: 1000 PSID
- Maximum Allowable Differential (Intermittent): 2 kgf/cm²
- Cracking Pressure Differential (Comb Manifold): 2 kgf/cm²
- Full-Open Differential (Comb Manifold): 0.8 kgf/cm²
Temperature Capabilities:
- Standard Range: -20°F to 150°F (-28.9°C to 65.6°C)
- Extended range options available for special applications
Flow Capacity:
- Maximum Flow: Up to 39,000,000 SCFH (12" valve at 700 PSIG outlet, 1480 PSIG inlet)
Sizes Available:
- 2", 3", 4", 6", 8", 10", 12" (DN50 to DN300)
