Technical Specifications:
Model: TARTARINI A142 / 142-AP Spring Loaded Pressure Regulator
Type: Direct-operated spring loaded regulator
Inlet Pressure: 0.2-10 bar (3-145 psi)
Outlet Pressure: 0.01-2 bar (0.15-29 psi) adjustable
Flow Capacity: Up to 1,500 Nm³/h
Accuracy: ±5% of setpoint
Spring Type: Adjustable coil spring
Body Material: Aluminum alloy (EN AC-44300)
Internal Components: Stainless steel
Diaphragm: Nitrile rubber (NBR) standard
Operating Temperature: -20°C to +60°C
Connection Sizes: DN15 to DN50 (½"-2" flanges)
Pressure Rating: PN16
Adjustment Method: Manual spring adjustment screw
Locking Feature: Locknut for setpoint security
Relief Mechanism: Built-in safety relief (optional)
Certifications: EN 334, CE marked
Installation: Horizontal or vertical mounting
Maintenance: Minimal, spring tension adjustment only
