BP3-1A11B5J111 GO Regulator Booster Back Pressure Valve 0-500 PSIG SS316L
BP3-1A11B5J111 GO Valve Back Pressure Regulator: Panel mount design, 0-500 PSIG, 316L SS, PTFE diaphragm, Cv 0.20.
Product Details
The BP3-1A11B5J114 GO Valve Back Pressure Regulator delivers precision pressure control specifically engineered for instrumentation systems requiring reliable liquid and gas service. Operating within a control range of 0 to 500 psig with maximum operating pressure of 500 psig, this back pressure regulator maintains constant upstream pressure through precise throttling action, offering superior performance compared to traditional relief valves. Constructed from 316L stainless steel body with CF PTFE seat and diaphragm materials, the BP3-1A11B5J114 ensures exceptional corrosion resistance and bubble-tight shutoff capabilities. Featuring 1/4" female NPT process ports, gauge ports, and a flow coefficient (Cv) of 0.20, this unit accommodates diverse applications including analytical instrumentation, gas and liquid sampling, petrochemical processing, air compressors, research laboratories, and pilot plants. The regulator operates effectively across temperatures ranging from -40°C to 93°C (-40°F to 200°F) with standard internal surface finish less than 25 Ra. Distinguished by its panel mount bonnet assembly requiring 1-3/8 inch mounting holes, this back pressure regulator offers convenient installation in control panels and equipment racks. Optional configurations include additional material choices such as Brass, Monel®, Hastelloy® C-276, and Titanium, plus extra ports and high purity connections. This regulator's robust design and precise pressure control make it ideal for critical process environments demanding accuracy and reliability in pressure regulation applications.
