Orifi ce [mm] DN 0.8 – 1.6 (for details see ordering chart)
Body material PPS
Seal material FKM, EPDM
Medium Resistant to neutral liquids and gases (see Bürkert chemical
resistance chart)
Media temperature -10 to 55 °C 1)
Ambient temperature max. 55 °C
Viscosity max. 21mm2/S
Internal volume
with sub-base
on request
starting at 44 μl
< 10 μl 2)
Port connection Bürkert sub-base (16 x 27 mm)
Electrical connection Cable plug Type 2505
Tag connector acc. DIN 43650 C for Cable plug
Type 2506 above
2 FEP-Flying leads, AWG24, lenght 500 mm 3)
Operating voltage 12 and 24 V/DC; other Voltages on request
Voltage tolerance ± 10 %
Power consumption 3.4 W
Duty cycle continuous rating 100 % ED
Installation as required, preferably with actuator upright
Protection class IP 65 with fl ying leads or cable plug
IP 40 with Rectangular plug
Response times
Opening
Closing
acc. ISO 12238:2001; Measured at valve outlet at 2 bar and
+20 ºC
approx 25 ms (Pressure range 0 to 10 %)
approx 25 ms (Pressure range 100 to 90 %)
