Honeywell-AMCO 1803 2″ Natural gas regulator
Honeywell AMCO 1803 2" spring-loaded gas regulator, max 125 PSI inlet, 3.5" W.C. to 5 PSI outlet, cast iron body, 733 Nm³/h.
Product Details
Applications: Commercial and industrial gas distribution, burner systems, vaporizer units, gas supply for industrial processes, LPG second-stage pressure regulation, and natural gas service lines.
1800 Series AMC0 Medium Spring-Loaded Pressure Regulators feature a valve head pre-fitted to a cast iron body to prevent thread damage and allow easy conversion into a monitoring regulator. They offer a wide flow range, high accuracy, and high shut-off pressure. Each orifice can be used with two standard types as well as the 0PS0 type. The 0PS0 type provides ultra-high shut-off pressure, making it suitable for protecting public facilities such as schools and churches. These regulators are suitable for various types of industrial users and can operate in ambient temperatures ranging from -30°C to +65°C.
Main Technical Parameters
- Maximum Inlet Pressure: 10.6 kgf/cm²
- Outlet Pressure: 0.87 kPa ~ 34.5 kPa
- Maximum Flow Rate: 733 Nm³/h
- Operating Temperature: -30°C ~ 65°C
- Valve Body Connections: 1‑1/2″, 2″ NPT Thread, 2″ Flange
- Standard Configuration: 1‑1/2″, 2″ NPT Thread
Model Specifications
表格
| Model | Additional Features | Exhaust Port |
|---|---|---|
| 1803 | None | 3/4″ NPT |
| 1803M | Monitoring Pressure Regulation | 3/4″ NPT |
| 1813 | Minor Internal Release | 1″ NPT |
| 1813B | Major Internal Release | 2″ NPT |
| 1823 | Low Pressure Cutoff | 3/4″ NPT |
| 1833 | Minor Internal Release, Low Pressure Cutoff | 1″ NPT |
| 1833B | Major Internal Release, Low Pressure Cutoff | 2″ NPT |
| 1843 | Minor Internal Release, Overpressure Cutoff | 1″ NPT |
| 1843B | Major Internal Release, Overpressure Cutoff | 2″ NPT |
| 1853 | Minor Internal Release, Overpressure Cutoff, Low Pressure Cutoff | 1″ NPT |
| 1853B | Major Internal Release, Overpressure Cutoff, Low Pressure Cutoff | 2″ NPT |
| 1883 | Overpressure Cutoff | 3/4″ NPT |
| 1883M | Overpressure Cutoff, Monitoring Pressure Regulation | 3/4″ NPT |
| 1893 | Overpressure Cutoff, Low Pressure Cutoff | 3/4″ NPT |
