FISHER MR95H-121 Emerson Fisher MR95H-121 Compact Direct-Operated Pressure Reducing Valve
FISHER MR95H-121: High-pressure regulator, 5-150 psig outlet, 1000 psig inlet, compact industrial design.
Product Details
Brand: FISHER
Type: Pressure Reducing Valve
Model: 95H-121
Valve Body Material: Cast Iron
Spring Seat Material: Cast Iron
Diaphragm Material: Nitrile Rubber
Technical Specifications: DN50 2 INCH, Outlet Pressure: 5-80 PSI
Maximum Pressure: 300 PSI
FISHER MR95H-121 is a high-pressure, direct-operated industrial pressure regulator designed for demanding applications in oil and gas, chemical processing, and industrial manufacturing. Manufactured by Emerson, this regulator is part of the MR95H series known for compact design and large capacity performance.
The MR95H-121 features an outlet pressure range of 5 to 150 psig (0.35 to 10.3 bar) with a maximum inlet pressure capacity of 1000 psig (69.0 bar) and maximum outlet pressure of 450 psig (31.0 bar), making it suitable for high-pressure drop applications. The valve body is available in multiple materials including gray cast iron, WCC steel, LCC steel, and stainless steel, with special alloy options (Monel, Hastelloy C, aluminum bronze) for corrosive service conditions.
